BAT104-NiMh

• Nickel Metal Hydride batteries
• 7AA x 2.7A Hr. with digital temp. sensor
• Size: 3.78" x 3.50" x 0.592" (96.01 x 88.9 x 15.04 mm)
• Weight: 7.78oz / 220.45g
• Temperature range: 0°C to +40°C (Standard charge), 0°C to +50°C (Discharge),
  -20°C to +50°C (Storage < 1month)

The BAT104-NiMh creates a complete NiMh UPS system by plugging directly into the bottom of the HESC (including the V5SC-SER) Vehicle Power Supplies. The BAT104-NiMh includes seven 2300ma-hr NiMh batteries for a total of 19.3 watt-hours of power. Therefore a BAT104-NiMh can supply backup power for up to sixty minutes to a 19.3 watt load.

The BAT104-NiMh includes Mosfet transistors for preventing deep discharge occurrences during extended power outages. The Mosfet transistors electrically isolate the BAT104-NiMh from the HESC whenever the BE output of the HESC is de-asserted (pulled to 5V).

The BAT104-NiMh has both a thermal fuse and a current fuse for protection against overcharging, and shorts on the battery output.

A digital I2C temperature sensor provides temperature feedback for charge termination, which can be read by the HESC.
