M-Max 7XX PR5 Platform

Optimal performance and good expandability
  • Details
  • Specification
  • Atom E3825 CPU
  • 2 or 4 GB of RAM
  • Power consumption: 10 W
  • Operating Temperature: up to -40°C to +70°C (-40°F to +158°F)
  • Compatible M-Max Systems: PD 7, VT, ATR, HR 1U, HR 3U

The M-Max 7XX PR5 platform will fit applications which require both optimal performance and low power consumption while offering better expandability in comparison with M-Max 6XX LP.

M-Max 7XX PR5 is equipped with 2-core Atom E3825 1.33 GHz CPU and can carry 2 or 4 GB of RAM. Storage options include SSDs from 8 GB via mSATA2 and SATA2.

M-Max 7XX PR5 uses HD 7th Generation 533 MHz for video processing and VGA interface for video output. Audio interfaces include 2 inputs, 6 outputs, 2 mic inputs and SPDIF. Other interfaces include 2x Gigabit Ethernet, 2x USB 2.0, 1x USB 3.0, 2x + 2x(lim.) RS-232/485 and 8x DIO lines.

Power consumption of the platform is 10 W. Operating temperature for M-Max 7XX PR5-based system is −20°C to +55°C (-4°F to +131°F) and expandable to −40°C to +70°C (-40°F to +158°F). The standard enclosure for the M-Max 7XX PR5 platform is Versatainer.

The M-Max 7XX PR5 platform is compatible with the following M-Max Systems: PD 7, VT, ATR, HR 1U, HR 3U.

Technical specifications
CPU:Atom E3825 1.33 GHz 2 Cores / 2 Threads
RAM (min / max):2 / 4 GB
GPU:HD 7th Gen. 533 MHz
SSD (min):mSATA2 + SATA2 8 GB
Video:VGA
Audio:2x IN + 6x OUT + 2x Mic + SPDIF
GbE/Fast Ethernet:2/-
USB 2.0/3.x:2/1
RS-232/485:2+2(lim.)
DIO:8
Power consumption:10 W
Compatible M-Max Systems:PD 7
VT
ATR
HR 1U
HR 3U

Environmental and physical specifications

Operating Temperature:-20°C to +55°C (-4°F to +131°F)
-40°C to +70°C (-40°F to +158°F) (optional)
Protection:IP65-IP66
Vibration / Shock:2.5-6g / 10-40g @ 11 ms
