M-Max 7XX PR7 Platform

Optimal performance and good expandability
  • Details
  • Specification
  • Atom E3826 or E3845 CPU
  • 2 or 4 GB of RAM
  • Power consumption: 11 W / 14 W
  • Operating Temperature: -40°C to +70°C (-40°F to +158°F)
  • Compatible M-Max Systems: PD 7, VT, ATR, HR 1U, HR 3U, VI

The M-Max 7XX PR7 platform will fit applications which require both optimal performance and low power consumption while offering better expandability in comparison with M-Max 6XX LP.

The choice of CPUs for M-Max 7XX PR7 includes 2-core Atom E3826 1.46 GHz and Atom E3845 1.91 GHz. The platform can be equipped with either 2 or 4 GB of RAM (soldered on board). Storage options include SSDs from 8 GB via mSATA2 and SATA2 interfaces.

M-Max 7XX PR7 uses HD 7th Generation 533-667 MHz or 542-792 MHz for video processing and either VGA or HDMI + DP interfaces for video output. Audio interfaces include 2x inputs, 2x outputs, and 1x mic input. Other interfaces include 2x Gigabit Ethernet, 2x USB 2.0, 1x USB 3.0, 4x(lim.) RS-232/485 and 16x DIO lines.

Power consumption of the platform is 11 W or 14 W depending on the chosen configuration. Operating temperature for M-Max 7XX PR7-based system is −40°C to +70°C (-40°F to +158°F). The standard enclosure for the M-Max 7XX PR7 platform is Versatainer.

The M-Max 7XX PR7 platform is compatible with the following M-Max Systems: PD 7, VT, ATR, HR 1U, HR 3U, VI.

Technical specifications
CPU:Atom E3826 1.46 GHz 2 Cores / 2 Threads,
Atom E3845 1.91 GHz 4 Cores / 4 Threads
RAM (min / max):2 / 4 GB (soldered)
GPU:HD 7th Gen. 533–667 / 542–792 MHz
SSD (min):mSATA2 + SATA2 8 GB
Video:VGA + HDMI / DP
Audio:2x IN + 2x OUT + 1x Mic
GbE/Fast Ethernet:2/-
USB 2.0/3.x:2/1
RS-232/485:4(lim.)
DIO:16
Power consumption:11 W / 14 W
Compatible M-Max Systems:PD 7
VT
ATR
HR 1U

HR 3U
VI

Environmental and physical specifications

Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Protection:IP65-IP66
Vibration / Shock:2.5-6g / 10-40g @ 11 ms
