PCIEcan 2xCAN v3
CAN multi-channel real time CAN interface with two CAN/CAN FD channels
Vendor:Kvaser AB
- Details
- Specification
- Order information
- Supports CAN FD, up to 8 Mbit/s
- High-speed CAN connection, up to 1 Mbit/s
- Quick and easy plug-and-play installation
- Operating temperature: -40 to 85 °C
Kvaser PCIEcan 2xCAN v3 is a small, yet advanced, CAN multi-channel real time CAN interface that handles transmission and reception of standard and extended CAN messages on the bus with a high time stamp precision. The Kvaser PCIEcan 2xCAN v3 is compatible with applications that use Kvaser‘s CANlib.
Major features
- PCI Express CAN interface
- Supports CAN FD, up to 8 Mbit/s
- Quick and easy plug-and-play installation
- Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers
- 100 % compatible with applications written for other Kvaser CAN hardware with Kvaser CANlib
- High-speed CAN connection (compliant with ISO 11898-2), up to 1 Mbit /s
- Fully compatible with J1939, CANopen, NMEA 2000 and DeviceNet
- Support for SocketCAN
- Supports silent mode for analysis tools — listen to the bus without interfering
- Supports simultaneous usage of multiple Kvaser interfaces
- Low profile board, includes low and high profile brackets
| Technical specifications | |
| CAN Channels | 2 |
| CAN Bit Rate | 20-1000 kbp/s |
| CAN FD Bit Rate | Up to 8 Mbit/s |
| Error Frame Detection | Yes |
| Error Frame Generation | Yes |
| Silent Mode | Yes |
| Timestamp Resolution | 1 µs |
| Galvanic Isolation | Yes |
| Power Consumption | 700-1000 mW |
| Interfaces | CAN, PCI |
| Connectors | D-SUB 9 |
| Operating Systems | Linux, Windows |
| Dimensions | Low profile 86 x 69 mm |
| Weight | 49 g (129 g with cable) |
|
Environmental and physical specifications |
|
|---|---|
| Temperature Range | -40 to 85 °C |
| Certificates | CE, RoHS |
| Model | Description |
| 73‑30130‑01432‑9 | CAN multi-channel real time CAN interface with two CAN/CAN FD channels |
