M-Max 6XX LP Platform

Optimal performance and low power consumption
  • Details
  • Specification
  • Apalis i.MX6 800 MHz CPU
  • 2 GB of RAM (soldered)
  • Power consumption: 3 W
  • Operating temperature: -40°C to +70°C (-40°F to +158°F)
  • Compatible M-Max Systems: PD 2, HR 1U

The M-Max 6XX LP platform is a good choice when low power consumption is critical. For this platform it adds up to just 3 W.

M-Max 6XX LP uses Apalis i.MX6 800 MHz CPU which performance is comparable with Intel Atom CPU from our next M-Max 7XX series platform. It has 2 GB of RAM and SSD soldered on board. Storage space is expandable via mSATA interface.

The standard version offers enough I/O interfaces for a variety of applications. The platform is equipped with both VGA and HDMI outputs and uses Vivante GC2000 for video processing. Other interfaces include 2 audio inputs, 2 audio outputs, 1 mic input, 1x Gigabit Ethernet, 4x USB 2.0, 2x RS-232 (lim.), 2x RS-232/485 and 8x DIO lines.

Operating temperature of M-Max 6XX LP-based system is −40°C to +70°C (-40°F to +158°F). The standard enclosure for the platform is Pandora 3″.

The M-Max 6XX LP platform is compatible with the following M-Max Systems: PD 2, HR 1U.

Technical specifications
CPU:ARM i.MX6 800 MHz 4 Cores / 4 Threads
RAM:2 GB (soldered)
GPU:Vivante GC2000
SSD (min):mSATA 4 GB (soldered)
Video:VGA + HDMI
Audio:2x IN + 2x OUT + 1x Mic
GbE/Fast Ethernet:1/-
USB 2.0/3.x:4/-
RS-232:2 (lim.)
RS-232/485:2
DIO:8
Power consumption:3 W
Compatible M-Max Systems:PD 2
HR 1U

Environmental and physical specifications

Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Protection:IP65-IP66
Vibration / Shock:2.5-6g / 10-40g @ 11 ms
