M-Max V75 Short chassis

Rugged VITA 75 conduction-cooled enclosure
  • Details
  • Specification
  • Material: Aluminum T6061
  • Shock handling up to 10g, Vibration up to 2g
  • IP66 rated dust and moisture protection
  • Operating temperature from -40 to +75 °C

The M-Max V75 Short chassis is a fully sealed rugged enclosure with passive cooling designed according to VITA 75 footprint, providing reliable operation in tough environments including transportation (ground, rail, air and marine), agriculture, mining and processing.

The machine-worked aluminum chassis is especially designed for the most challenging environments. Providing excellent shock and vibration protection, the completely fanless chassis uses natural convection and conduction cooling.

Typical systems housed in this VITA 75-compliant enclosure deliver IP66 dust and moisture protection, withstand shocks up to 10g and vibration up to 2g. The fully sealed enclosure houses one PC/104 or similar-sized board. The configurable front panel can be outfitted with variety of customer-defined connectors. The M-Max V75 Short chassis is tested and guaranteed over temperature range of −40 to +75°C.

MicroMax, as a manufacturer of ruggedized industrial computers, takes a customized approach to each client. Our engineering group can design M-Max systems to fit customer-specific technical requirements.

  • Show more
Technical specifications
Material: Aluminum T6061
Heat dissipation: 14W
Cooling system: Natural convection and conduction cooling for inside module;
Natural convection cooling for outside surfaces
Capacity: One PC/104 or similar board
Mechanical (W x H x L): 203.2 x 38 x 188 mm (without end caps and connectors)
Weight: 1430 g / 3.15 lbs

Environmental and physical specifications for typical systems

Dust/Moisture: IP66
Operating Temperature: -40 to +75 °C @ 14W
Humidity: Operating: 5 to 95 % at +25 °C, non-condensing
Vibration Operating acceleration amplitude up to 2g
Shock: Maximum peak shock acceleration up to 10 g (15 ms)
