AR Platform

High performance and upgrade opportunities
  • Details
  • Specification
  • i3-6102E / i3-6100E CPU
  • 8 / 16 GB of RAM
  • Power consumption: 45 / 55 W
  • Operating temperature: -40°C to +65°C (-40°F to +149°F)
  • Compatible M-Max® Systems: VT, ATR, HR 3U

The AR Platform provides high performance and vast upgrade opportunities.

The AR Platform can be equipped with either 2-core i3-6102E 1.9 GHz or i3-6100E 2.7 GHz CPU, 8 or 16 GB of RAM (soldered) and SSD from 8 or 32 GB via embedded SATA2 and 2x SATA3 interfaces. The AR Platform uses Intel HD 530 0.35–0.95 GHz for video processing and DP + HDMI for video output.

Other interfaces include 2x Gigabit Ethernet, 4x USB 2.0, 1x USB 3.0 2x RS-232 and 8 DIO lines. Power consumption is 45 or 55 W depending on the chosen configuration. Operating temperature is −20°C to +60°C (-40°F to +140°F), expandable to −40°C to +65°C (-40°F to +149°F).

The AR Platform is compatible with the following M-Max® Systems: VT, ATR, HR 3U.

Technical specifications
CPU: i3-6102E 1.9 GHz 2 Cores / 4 Threads,
i3-6100E 2.7 GHz 2 Cores / 4 Threads
RAM (min / max): 8 / 16 GB (soldered)
GPU: HD 530 0.35–0.95 GHz
SSD (min): Embedded SATA2 + 2x SATA3 8 / 32 GB (soldered)
Expansion boards:PCI/104-Express (Type I, Gen 3)
Video: DP + HDMI
GbE: 2
USB 2.0/3.x: 4/1
RS-232: 2
DIO: 8
Power consumption: 45 W / 55 W
Compatible M-Max® Systems: VT
ATR
HR 3U

Environmental and physical specifications

Operating temperature: -20°C to +60°C (-40°F to +140°F)
-40°C to +65°C (-40°F to +149°F) (optional)
Vibration / Shock: 2.5-6g (3–500 Hz) / 10-40g @ 11 ms
