DT Platform

High performance and upgrade opportunities
  • Details
  • Specification
  • i7-6600U CPU
  • 4 / 20 GB of RAM
  • Power consumption: 21 W
  • Operating temperature: -40°C to +70°C (-40°F to +158°F)
  • Compatible M-Max® Systems: ATR, HR 1U, HR 3U

The DT Platform provides high performance and vast upgrade opportunities.

The DT Platform carries 2-core i7-6600U 2.6-3.4 GHz CPU, 4 to 20 GB of RAM (soldered) and SSD from 8 GB via mSATA3 and 2x SATA3 interfaces. The platform uses Intel HD 520 0.3–1.0 GHz for video processing and VGA + HDMI for video output. Audio interfaces include 2x inputs, 2x outputs, and 1x mic input.

Other interfaces include 2x Gigabit Ethernet, 2x USB 2.0, 4x USB 3.0, 4x RS-232/485 (lim.) and 16 DIO lines. Power consumption is 21 W. Operating temperature is -40°C to +65°C (-40°F to +149°F).

The DT Platform is compatible with the following M-Max® Systems: ATR, HR 1U, HR 3U.

Technical specifications
CPU: i7-6600U 2.6-3.4 GHz 2 Cores / 4 Threads
RAM (min / max): 4 (soldered) / 20 GB
GPU: HD 520 0.3–1.0 GHz
SSD (min): mSATA3 + 2x SATA3 8 GB
Expansion boards:PCI/104-Express (1x bank, Gen 3)
Video: VGA + HDMI
Audio: 2x IN + 2x OUT + 1x Mic
GbE: 2
USB 2.0/3.x: 2/4
RS-232/485: 4 (lim.)
DIO: 16
Power consumption: 21 W
Compatible M-Max® Systems: ATR

Environmental and physical specifications

Operating temperature: -40°C to +70°C (-40°F to +158°F)
Vibration / Shock: 2.5-6g (3–500 Hz) / 10-40g @ 11 ms
