EP4 Platform

High performance and upgrade opportunities
  • Details
  • Specification
  • Intel Celeron to Intel Xeon CPU options
  • 8 to 48 GB of RAM
  • Power consumption: 55 / 65 W
  • Operating temperature: up to -40°C to +60°C (-40°F to +140°F)
  • Compatible M-Max® Systems: ATR, HR 3U, VI

The EP4 Platform provides high performance and vast upgrade opportunities.

The EP4 platform offers a wide range of CPU options from Intel Celeron to Intel Xeon, 8 to 48 GB of RAM and SSD from 8 GB via 2x mSATA3 and SATA3 interfaces. The platform uses Intel UHD 610, UHD 630, HD Graphics 630, or UHD Graphics P630 for video processing and either 2x HDMI, DP or DVI for video output. Audio interfaces include 2x headphones outputs and 2x mic inputs.

Other interfaces include 2x Gigabit Ethernet, 4x USB 3.0 and 2x(lim.) RS-232/485. Power consumption is either 55 or 65 W depending on the chosen configuration. Operating temperature is −20°C to +55°C (-4°F to +131°F), expandable to −40°C to +60°C (-40°F to +140°F).

The EP4 Platform is compatible with the following M-Max® Systems: ATR, HR 3U, VI.

Technical specifications
Compatible M-Max® Systems: ATR
HR 3U
VI
CPU options: Intel Pentium G5600E, 35W, 2 Cores / GT1
Intel Celeron G4930E, 35W, 2 Cores / GT1
Intel Celeron G4932E, 25W, 2 Cores / GT1

Intel Core i7-7820EQ
Intel Core i5-7440EQ
Intel Core i5-7442EQ
Intel Core i3-7100E
Intel Core i3-7102E

8th Intel Core i7-8850H
8th Intel Core i5-8400H
8th Intel Core i3-8100H

Intel Core i7-9850HE, 45W (35W cTDP), 6 Cores / GT2
Intel Core i7-9850HL, 25W, 6 Cores / GT2
Intel Core i3-9100HL, 25W, 4 Cores / GT2

8th Intel Xeon E-2176M
Intel Xeon E-2276ME, 45W (35W cTDP), 6 Cores / GT2
Intel Xeon E-2276ML, 25W, 6 Cores /GT2
Intel Xeon E-2254ME, 45W (35W cTDP), 4 Cores / GT2
Intel Xeon E-2254ML, 25W, 4 Cores /GT2
RAM (min / max): 8 / 48 GB
GPU options: Intel UHD 610
UHD 630
HD Graphics 630
UHD Graphics P630
SSD (min): 2x mSATA3 + SATA3 8 GB
Expansion boards: PCIe/104 (Type I or II, Gen 3)
2x MiniPCIe
Video: 2x HDMI / DP / DVI
Audio: 2x HP + 2x Mic
GbE 2
USB 3.x: 4
RS-232/485: 2 (lim.)
Power consumption: 55W / 65W

Environmental and physical specifications

Operating Temperature: -20°C to +55°C (-4°F to +131°F)
-40°C to +60°C (-40°F to +140°F) (optional)
Vibration / Shock: 2.5-6g / 10-40g @ 11 ms
