The M-Max^® HR 1U DT  (M-Max^® HR 1U System) rugged industrial system provides reliable operation in tough environments.

The fully-ruggedized 19/2"-type aluminum chassis is fanless and uses natural convection and conduction cooling in accordance with MIL-STD-810 standards. Versatile mechanical design of the enclosure allows to combine several systems into one assembly side by side or by stacking, mount them on a flat surface or into a 19″ rack using appropriate mounting parts. COTS technology components allow configuring the system to comply with a wide variety of airborne, marine and ground vehicle applications.

The M-Max^® HR 1U DT is based on the M-Max^® HR 1U Systems Family.

• IP66-rated dust and moisture protection
• Shock handling up to 40g, Vibration up to 2.5g
• Power consumption: 21 W
• Operating Temperature: up to -40 to +70 °C

The M-Max^® HR 3U CU (M-Max^® HR 3U System) is a high-performance rugged industrial computer provides reliable operation in tough environments. The fully-ruggedized 19/2"-type aluminum chassis is fanless and uses natural convection and conduction cooling in accordance with MIL-STD-810 standards. COTS technology components allow configuring the M-Max^® HR 3U family to comply with a wide variety of airborne, marine and ground vehicle applications.

Delivering outstanding performance comparable to high-end desktop systems, it also features extended graphics capabilities, providing up to 6x HDMI outputs.

• High performance Intel Xeon E3-1505L V5, 2.0-2.8 GHz
• Nvidia GeForce GTX 1050Ti graphics controller
• IP66 rated dust and moisture protection
• Shock handling up to 40g, Vibration up to 2.5g
• Operating Temperature: −40 to +50 °C

The M-Max^® ATR CU (M-Max^® ATR System) high-performance rugged industrial computer provides reliable operation in tough environments. The fully-ruggedized ATR-type aluminum chassis is fanless and uses natural convection and conduction cooling in accordance with MIL-STD-810 standards. COTS technology components allow configuring the M-Max^® ATR CU family to comply with a wide variety of airborne, marine and ground vehicle applications. Delivering outstanding performance comparable to high-end desktop systems, it also features extended graphics capabilities, providing up to 6x HDMI outputs.

• High performance Intel Xeon E3-1505L V5, 2.0–2.8 GHz
• Nvidia GeForce GTX 1050Ti graphics controller
• IP66 rated dust and moisture protection
• Shock handling up to 40g, Vibration up to 2.5g
• Operating Temperature: -40 to +50 °C

The M-Max^® 400 TBT is an ATR type rugged computer system for mission-critical applications incorporating three high performance i7 CPUs, an embedded 16-port switch and a removable SSD into one highly rugged sealed enclosure.

• 3x Single Board Computers inside one aluminum chassis
• Operating temperature from −30 to +55 °C
• IP66 rated dust and moisture protection
• Shock handling up to 10g, vibration up to 2.5g
• Removable SSD
• Embedded 16-port Gigabit switch

The M-Max^® PD2 LP (M-Max^® PD 2 System) is a small size, low weight and ultra low power consumption ARM based rugged industrial computer offering operation at a minute 4 watts. Designed for reliable operation in harsh environments, it utilizes MicroMax’s patented technology for passive cooling.

• Power consumption is only 4 W
• Operating temperature from −40 to +70 °C
• IP66 rated dust and moisture protection
• Shock handling up to 10g, Vibration up to 2.5g

The M-Max^® 720 PR7 is a high performance battery powered rugged computer system for mission-critical applications. The system is designed to operate in extremely harsh environments and is equipped with: GPS module, 900 MHz Radio modem, 48x Isolated Digital I/O interfaces, four functional LEDs, expanded set of RS-232/485, USB 2.0, VGA and Gigabit Ethernet ports. The system’s LiFePO4-battery based UPS provides 10 hours of backup power and supports an online connection to the optional M-Max^® B00 external Rugged Battery unit.

• Integrated and External LiFePO4 batteries
• Hot swappable external battery unit
• 20+ hours of backup power at 100% CPU load
• 18 W power consumption
• Shock handling up to 10g, Vibration up to 2g
• Data storage based on industrial grade SSDs
• Operating Temperature (using the power of installed batteries) from −20 to +65 °C

The M-Max^® VI PR7 (M-Max^® VI System) is a Quad Core rugged industrial computer with data acquisition features for tough environments. The enclosure is designed according to the VITA 75 footprint and can be mounted on different vehicle types. The lightweight compact sealed case with fanless heat dissipation resists contamination and humidity. The system has been certified to comply with MIL-STD-810G and airborne MIL-STD-704F. The system is expandable by one mPCIe module and one PCI/104 Plus board.

• Certified to comply with MIL-STD-704F and MIL-STD-810G
• Operating temperature from −40 to +70 °C
• IP66 rated dust and moisture protection
• Shock handling up to 40g, Vibration up to 2.5g
• 16x digital programmable I/O lines
• Optional: 16×16-bit analog inputs, 250 KHz max sample rate; 4×16-bit analog outputs; 6x additional DIO lines

The MicroMax family of Rugged Switches, comprised of the M-Max^® SW216 and M-Max^® SW21X/PS, is a lineup of ruggedized Gigabit Ethernet Layer 2+ Managed Switches providing reliable operation in tough environments. Their rugged enclosures are designed according to the VITA75 footprint. The M-Max^® SW216 offers 16x Gigabit Ethernet ports. The M-Max^® SW21X/PS can be equipped with either 12x, 14x or 16x Gigabit Ethernet ports. The M-Max^® SW21X/PS is in compliance with MIL-STD-810G and MIL-STD-461F and its embedded power supply is in compliance with MIL-STD-704F and MIL-STD-1275D.

• Built-in microcontroller with software supporting host interface and management through web interface
• IP66 rated dust and moisture protection
• Operating temperature from −40 to +70 °C
• Wide power supply voltage input from +5 to +34 V DC or +28 V DC (complies with MIL-STD-704F, MIL-STD-1275D)
• Extended salty fog protection (available upon request)

The M-Max^® ATR 12 EP4 (M-Max^® ATR System) is a rugged industrial computer with the highest performance currently available for systems with passive cooling. It is designed to provide reliable operation in harsh environments. The fully-ruggedized ATR-type aluminum chassis is fanless and utilizes natural convection and conduction cooling in accordance with MIL-STD-810 standards. The sealed enclosure of the ATR-system is designed specifically for PC/104 form-factor boards.

• Complies with MIL-STD-810G specifications
• Operating temperature from −40 to +60 °C
• Shock handling up to 40g, Vibration up to 2.5g
• IP66 rated dust and moisture protection
• High performance system, Intel Quad Core i7 based
• Optional: 28VDC input compliant with MIL-STD-704F, MIL-STD-461F

The M-Max^® ATR-compliant chassis is a fully sealed rugged enclosure with passive cooling, providing extreme physical protection for high performance systems. The machine-worked aluminum chassis is especially designed for the most challenging environments. The completely fanless chassis uses natural convection and conduction cooling. Typical systems housed in this ATR-compliant enclosure deliver IP66 dust and moisture protection, withstand shocks up to 40g and vibration up to 2.5g. The fully sealed enclosure houses up to 8 PC/104 or similar-sized boards.

• Dissipates up to 95 W of power using only passive cooling
• Configured to house PC/104, ComExpress and EBX boards simultaneously
• Up to 8 PC/104 or similar-sized boards in 1/2 Short enclosure
• Configurable front and rear panels
• Optional: 100W power supply (28VDC) compliant with MIL-STD-704F, MIL-STD-461F

The M-Max^® 400 RC is a highly reliable compact rugged computer for building all-electric interlocking distributed systems. The system is designed for converting CAN-interface control signals into relay control signals of railroad automation systems. It uses ‘2 out of 2’ architecture for higher reliability of control signals. Two autonomous identical computers inside the system are connected by internal interfaces. Each computer has an independent power input and an internal uninterruptible power supply (UPS) based on ultracapacitors, ensuring up to 40 seconds of operation with the input power cut off. Depending on configuration the system allows to maintain 12 or 24 relays.

• ‘2 out of 2’ architectures
• 40s run on internal UPS based on ultracapacitors
• Operating temperature from −40 to +65 °C
• Shock handling up to 10g, Vibration up to 2g

The M-Max^® VT AR TRN-02 (M-Max^® VT System) is a high-performance rugged industrial computer for demanding and critical applications requiring performance comparable to desktop systems. The system is IP66 rated and can withstand shocks of up to 40g and vibration of up to 6g. The M-Max^® VT AR TRN-02 is configured with Intel Core i3 1.9 GHz CPU and Intel HD 530 0.35–0.95 GHz video, with hardware video decoding. The M-Max^® VT AR TRN-02 has 5x LAN Gigabit Ethernet, 1x RS-232 and 3x USB 2.0 ports. Data storage options include vibration proof industrial SSDs with RAID functionality (software or hardware option).

• Complies with MIL-STD-810G specifications
• Operating temperature from −40 to +65 °C
• Shock handling up to 40g, Vibration up to 6g
• IP66 rated dust and moisture protection
• High performance system, Intel Core i3 based
• Optional: 28VDC input compliant with MIL-STD-704F, MIL-STD-461F
